HDMI 2.0b and HDCP 2.3 compliant
Uncompressed 4K2K@50/60Hz 4:4:4 up to 18Gbps video bandwidth
HDR, HDR10, HDR10+, Dolby Vision and HLG pass through
LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24,
DTS High Res, DTS-HD Master Audio, DSD pass through
Signal extended distance up to 328ft/100 meters via a single CAT6A/7
cable
Supports eARC/ARC function (the eARC/ARC audio is returned to the
HDMI IN port, HDMI OUT port and SPDIF OUT port of the transmitter.)
Supports SPDIF audio from RX to TX transmission
Bi-directional IR, RS-232 (only supports 115200bps) and 1G Ethernet
signal pass-through
Supports CEC pass-through
Bi-directional 24V POC function
