18Gbps 8x8 HDMI Matrix with ARC Function

☆ HDMI 2.0b, HDCP 2.2 and HDCP 1.4 compliant
☆ Video resolution up to 4K2K@60Hz (YUV 4:4:4) on all HDMI ports
☆ Support 18Gbps video bandwidth
☆ Dolby Vision, HDR10+ and HLG are supported.
☆ Support 4K->1080P Down Scaler for each output port
☆ HDMI audio pass-through up to 7.1CH HD audio (LPCM, Dolby TrueHD and DTS-HD
Master Audio)
☆ Audio de-embedded is supported via analog and coax ports
☆ ARC, CEC and smart EDID management are supported
☆ 1U rack mounted design with front panel OLED display
☆ Control via front panel buttons, IR remote, RS-232, LAN and Web GUI

  • Brand : Linetek
  • Category : Matrix
  • Sub Category : HDMI Matrix
  • Model No : LTK-MXB88DA
  • Input Type : 8XHDMI
  • Output Type : 8XHDMI
Download Brochure
